Operating weight :1800kg
Engine :Euro 5 LAIDONG385,/Kubota D722
Power:18.1 KW/10.2KW
Bucket:0.04CBM
Max Digging Depth:2100mm
Max Unloading Height:2368mm
The 18max-model mini excavator is an upgraded version of the 18U, with a larger operating space, higher configuration, full hydraulic control of the whole vehicle, and very gentle operation.
Technical parameters
| Engine Model | Kubota 722 |
| Power (kW/HP) | 10.2/13.64 |
| Main pump | Parker load triple load hydraulic gear pump |
| Bucket capacity | 0.03m³ |
| Max.Digging depth | 2200mm |
| Max.Unloading height | 2285mm |
| Operating weight | 1800kg |
| Total length | 2250mm |
| Total height | 2200mm |
| Total width | 1160mm |
Standard side swing.
Load sensitive multi way valve,can perform composite actions.
Flip up control box.
Newly upgraded designincreasing usage space.
Fully hydraulically controlledthe dozer bladeis controllednext to the right-hand joystick.
Rear cover flip design,seat front flip design,large opening area,convenient for later maintenance.
