Operating weight :1800kg
Engine :Euro 5 LAIDONG385,/Kubota D722 /Kubota D902 /YM374
Power:18.1 KW/10.2KW/11.8KW/10.8KW
Bucket:0.04CBM
Max Digging Depth:2100mm
Max Unloading Height:2368mm
The 18U mini excavator is the very popular model , with a larger operating space, higher configuration, full hydraulic control of the whole vehicle, and very gentle operation.
Technical parameters
| Engine Model | Laidong 385 |
| Power (kW/HP) | 18.9/39 |
| Main pump | Twin pumps Parker load hydraulic pump |
| Bucket capacity | 0.03m³ |
| Max.Digging depth | 2100mm |
| Max.Unloading height | 2185mm |
| Operating weight | 1800kg |
| Total length | 2250mm |
| Total height | 2200mm |
| Total width | 1160mm |
SW-18 is a compact, powerful small crawler excavator with a total operating weight of 1800 kg. It is designed for urban operations, landscaping, orchard construction and narrow space scenarios.
Standard side swing.
Load sensitive multi way valve,can perform composite actions.
Flip up control box.
Newly upgraded designincreasing usage space.
Fully hydraulically controlledthe dozer bladeis controllednext to the right-hand joystick.
Rear cover flip design,seat front flip design,large opening area,convenient for later maintenance.
